Will My Equipment Fit?

Preliminary Space Evaluations For Chemical Process Systems

How much space do we really need for this system?

This may seem like a simple question but comparing the size of a system with the space you'd like to install it in is often not a sufficient spatial assessment for chemical process systems. There are a number of considerations—from material flow to maintenance access and safety—which can impact the total space needed to support a system.


Download Your Guide

In this eBook, we cover the essentials of performing a preliminary space evaluation, including:

  • Definition of Process
  • Determining Area and Height Requirements
  • Items for Development in Detail Design

This eBook highlights many of the factors that can impact your spatial needs and runs through some examples to equip you to confidently answer the all-important question, "Will my equipment fit?"
